Quick Start Guide for the Techalogic Lc-1 Camera

1. Charge the Camera – Use the provided USB cable to fully charge the device before first use.
2. Insert a Memory Card – Supports Class 10, U3, V30 SD cards from 8GB to 512GB (Not Included).
3. Power On – Press and hold the Power Button for 2 seconds to turn on the LC-1.
4. Set Up Light Modes – Short press the Power Button to cycle through the six light modes (steady, flash, pulse, etc.).
5. Start Recording – Press the Recording Button once to begin recording. The blue indicator light will flash to confirm recording is active.

Connecting to the Viidure App

The LC-1 has a built-in WiFi interface for wireless connectivity to your smartphone.

How to Connect:

1. Download the Viidure App from the Apple App Store or Google Play Store.
2. Turn on WiFi – Press and hold the Recording Button for 3 seconds.
3. Connect Your Phone – Go to your phone’s WiFi settings, select "Techalogic", and enter the password: 12345678.
4. Open the Viidure App and tap “Connect DVR”.
5. Tap "Connect Device", then "Connect" to access live view and settings.

If you see a "No Internet Connection" warning, this is normal! Your phone is connected to the camera’s WiFi, not the internet.

Battery & Charging

• The 3500mAh battery provides 4-6 hours of continuous use depending on settings.
• Check the battery level using the touch-sensitive status indicator.
• The charging light remains on while charging and turns off once fully charged.

Ensure the LC-1 is powered off while charging for optimal battery performance.

Safety Light Modes

The 90-lumen safety light includes six modes:

1. Maximum Brightness
2. Medium Brightness
3. Flash
4. Pulse
5. Twilight Sensor Mode (Auto adjusts based on ambient light)
6. Off

Smart Light Mode automatically enables the light when riding in low-light conditions.

Reviewing & Transferring Files

Option 1: Using the Viidure App

1. Connect your phone to the LC-1 WiFi.
2. Open the Viidure App.
3. View, download, or delete recorded videos directly.

Option 2: Using an SD Card Reader

1. Power off the LC-1.
2. Remove the micro SD card.
3. Insert the card into a USB adapter or SD card reader.
4. Access the files on a computer or laptop.

Emergency Lock & G-Sensor

• The G-Sensor automatically locks footage in the event of a collision or sudden movement.
• Locked files are stored separately and cannot be overwritten by loop recording.
• If you don’t want files to lock, you can disable the G-Sensor in the Viidure App.

Water Resistance & Durability

• The LC-1 is IPX6-rated, meaning it can withstand heavy rain and wet conditions.
• Ensure the charging port cover is securely closed before riding in wet weather.

SD Card Maintenance

• Regular formatting is recommended every 2-3 months to maintain performance.
• Use high-endurance SD cards (e.g., Viofo or Integral) for maximum reliability.
• To format the card:
  • Use the Viidure App and follow on-screen prompts.
  • Alternatively, format via a computer (FAT32 or exFAT format required).

Always back up important files before formatting as this process will erase all data.

For detailed information on all features and additional settings, please refer to the full user manual provided with your camera.

Enjoy your LC-1, and happy recording!
